| REFERENCE | A +/- 0.1mm |
B +/- 0.2mm |
C mm |
D + 0.15 mm |
LOAD RATING Kg |
TUBE Ø x wall mm |
|---|---|---|---|---|---|---|
| BBP 20 x 1.5 | 17.1 | 30 | 10 | Ø6.2 | 5 | 20 x 1.5 |
| BBP 30 x 1.8 | 26.5 | 24.7 | 7 | Ø8.2 | 7 | 30 x 1.8/2 |
| BBP40 x 2.3 | 35.5 | 26.8 | 10 | Ø8.2 | 7 | 40 x 2.3 |
| BBP50 x 2.8 | 44.8 | 20.7 | 7 | Ø10.2 Ø12.2 11.2 Hex |
10 | 50 x 2.8 |
